Steam Shrink Tunnel HF-2000M
Tunnel length 2meters, this model is very common used for almost of bottles.
Email: bishop998@126.com
Tel/Whatsapp: 8613127538116
description1
Zipper closure
1/5 zip athletic pullovers for men. Stretchy, lightweight, fast-drying
fabric for superior performance.
REGULAR FIT - US standard sizes. An athletic fit that sits close to the
body
for a wide range of motion, designed for optimal performance and all day
comfort.
FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them
in
place during workout
bottle heat tunnel INTRODUCTION
(1) Superb shrink finish with filled or cold bottles
(2) Windows are installed inside of bottle heat tunnel’s body with water leaking holes, no water getting out.
(2) Windows are installed inside of bottle heat tunnel’s body with water leaking holes, no water getting out.
(3) Steam tubes are made of SS316 with rubber wrapping.
(4) Low running cost, 30kg steam/0.3~0.5Mpa.
(5) 6 Steam spray tubes are adjustable for complex shapes of bottles.
(6) Exhausting blower is on the top of tunnel, its speed is adjustable.
(7) Simple manual adjustment, and completed control.
(5) 6 Steam spray tubes are adjustable for complex shapes of bottles.
(6) Exhausting blower is on the top of tunnel, its speed is adjustable.
(7) Simple manual adjustment, and completed control.
(8) Precise steam control by 3 digital handles for 3 areas, and saving steam.
(9) Cancel outer water collection tray, sealed. Can be used for high speed applications.
(10) Full body of tunnel is made of SS304 stainless steel
(11) Strong and easy 0perational handles on windows.
(10) Full body of tunnel is made of SS304 stainless steel
(11) Strong and easy 0perational handles on windows.
(12) steam tubes are hided under bottle heat tunnel, simple and generous
(13) water outlet/water collection tray to avoid getting ground wet.
bottle heat tunnel PARAMETERS
|
Models |
HF-2000M/G |
|
Length of tunnel |
2.0meters |
|
Main material |
SS304 |
|
Braided steam soft tubes |
316 |
|
Blower powder |
Ø12, 0.25KW |
|
Running pressure |
Max 0.6Mpa |
|
Weight |
220kg |
|
Steam consumption |
50kg/h |
|
Powder supply of blower |
110~240V |
|
Entrance /exit height |
Max 350mm |
|
Entrance /exit width |
130~210mm |
|
Outline size (L*W*H, m) |
2.0*W0.45*1.5 |
* All specification and tooling requirements are subject to Accraply evaluation of all label and product samples. Specifications shown reflect standard machine capabilities. Accraply can also meet other specification requirements. Please email or call for details.
